Non-pressure solar water heater Color steel type
Non-pressure solar water heater Color steel type

Non-pressure solar water heater Color steel type

Model NO.
JX-NP-58/1800
Price:
US $ 100.00-150.00 / sets
Delivery:
FOB
Minimum order quantity:
10 sets
Country of Origin:
Shanghai or Ningbo port
Stock Time:
15 Days
Quantity:

Non-pressure solar water heater---Color steel JX-NP-58/1800

How it works

The design of this type uses the all-glass evacuated solar collector tubes as the heat absorb element. The high vacuum degree of the clearance between the outer and inner tube can reduce the heat emission which caused by convection and conduction to a very low level. All-glass evacuated tube transfers sun energy into heat energy by high absorption rate and low emittance rate of layer films. Depend on the different density between the hot water and the cold water, a cycle created in the tube which hot water ascending and cold water descending status. Keeping natural circulation like this, the water in the tank will be heated.

Material

1. Inner tank: SUS304-2B stainless steel

2. Outer tank: High quality color coated steel

3. Insulation: Polyurethane

4. Frame: 1.5/1.8/2.0/2.5mm aluminum alloy

Characteristics

1. Beautiful appearance, steady structure, higher grads.

2. Inner and outside water tank shell all are welded by argon arc.

3. The tubes and frame are adjustable, power bearing is average, and can assure the vacuum tubes to use long time.

  • Type:Evacuated Tube
  • Pressure:Unpressurized
  • Circulation Type:Direct / Open Loop (Active)
  • Certification:CE; RoHS
  • Place of Origin:Haining City, Zhejiang province, China
  • Brand Name:Lucky/OEM
